Myron PT4 Serbest Klor Dengi ve Sıcaklık Ölçer
0216 3527212
Serbest Klor Dengi(FCE ™) ve Sıcaklık Ölçüm Kalemi
ULTRAPEN™ PT4 Myron L® Company ABD nin yeni teknoloji harikasıdır. Serbest Klor Dezenfekte Gücü (FCE), Serbest Klor Dengini ve Sıcaklığı ölçer. Suya dayanıklıdır ve son derece hassas, hızlı olarak tasarlanmıştır. Su kalitesi ile ilgili muhtelif uygulamalarda kullanılır YENİ! FCE Suda mevcut klor(FAC) Fonksiyonlu
Myron L® Company FCE fonksiyonu, ORP( klorün kimyasal özelliği) ölçümü ile suda mevcut klorü (FAC) hızlı ve doğru olarak belirler, klorün kimyasal özelliği doğrudan etkinliğini aksettirir, pH ile çapraz referanslı olarak. DPD kiti ve renk ölçer, kullanıcıya test tüpündeki numunenin FAC değerlerini söyleyebilir, ama numunenin yapısı analiz edilen suyun kaynağından oldukça farklıdır. sonuç tam ve doğru olmayarak dezenfektan gücüyle ilgilidir.
Myron L® Company FCEfonksiyonu su kaynağının gerçek değişmemiş yapısını (bu yapıdaki anbean değişiklikler dahil) ölçer.
ULTRAPEN™ PT4 is Myron L® Company’s ground breaking, new Pocket Tester for measuring Free Chlorine Disinfecting Power, Free Chlorine Equivalent (FCE), as well as Temperature. It is waterproof and designed to be extremely accurate, fast, and simple to use in diverse water quality applications.
ULTRAPEN™ PT4 üstünlükleri:
- Güvenilir ve tekrarlanabilir Sonuçlar
- Doğru
- Hesaplı
- Kullanımı kolay
- Sağlam Tasarım
- Garantili Ürün Kalitesi
- Atık üretmez
- Çevreyi korur
YENİLİK! FCE TM Free Available Chlorine (FAC) Fonksiyonu
The Myron L® Company FCE function reports FAC quickly and accurately by measuring ORP, the chemical characteristic of chlorine that directly reflects its effectivity, cross referenced with pH. Both DPD kits and colorimeters may tell the user the FAC value of the sample in the test tube, but since the chemistry of that sample is quite different from the source water being analyzed, the results are imprecisely related to actual disinfection power. The Myron L® Company FCE function measures the real, unaltered chemistry of source water, including moment-to-moment changes in that chemistry.
ULTRAPEN™ PT4 Yüksek Performans Özellikleri:
- Accuracy of up to ±0.3 ppm FCE TM
- Calibration with pH and ORP Standard Solutions
- Automatic Temperature Compensation
- Live or Hold Mode – User Selectable
- Auto-Off Feature – User Adjustable
- Proprietary Sensor Design
- Easy to Use – One Button Control
- Rugged Design with Aircraft Aluminum Body
- Durable, Epoxy Encapsulated Electronics
- Waterproof
- Powered by One N Type Battery (Included)
ULTRAPEN™ PT4 COMES WITH:
- PT4 Pocket Tester Pen – Battery Installed
- User Replaceable FCE TM Sensor – Installed
- Protective/Hydration Cap
- Scoop
- Pocket Clip
- ORP Electrode Cleaning Paper
- Quick Start Guide
ULTRAPEN™ PT4 Measurement Modes:
| MODE | METHOD OF MEASUREMENT |
| Hold (default) | Once stabilized, the readings are captured then displayed. |
| LIVE | Real-time readings are displayed continuously during measurement. |
ULTRAPEN™ PT4 Specifications:
| FCE ™ Free Chlorine Range: | 0 – 10.0 ppm |
| FCE ™ Free Chlorine Accuracy: | < 5.00 ppm: ± 0.3 ppm, ≥ 5.00 ppm: ± 0.5 ppm |
| FCE ™ Free Chlorine Resolution: | 0.01 ppm |
| Temperature Range: | 0 – 71°C / 32 – 160°F |
| Temperature Accuracy: | ± 0.1ºC |
| Temperature Resolution: | 0.1ºC / 0.1ºF |
| Power Consumption: | Active Mode: 30 – 140 mA, Sleep Mode: 2 µA |
| Temperature Compensation: | pH : Automatic to 25°C ORP: Automatic in Calibration Mode from 15ºC to 30ºC |
| Physical Dimensions: | 17.15 cm L x 1,59 cm D or 6.75 in. L x .625 in. D |
| Weight: | 50.4 g / 1.78 oz. (without soaker cap and lanyard) |
| Case Material: | Anodized Aircraft Aluminum with Protective Coating |
| Battery Type: | One N type, Alkaline, 1.5 V |
| Calibration Standard Solutions: | PH4, PH7, PH10, ORP80, ORP260, ORP470 |
| Operating/Storage Temperature: | 0 – 55ºC / 32 – 131ºF |
| Enclosure Ratings: | IP67 and NEMA6 |
| EN61236-1: 2006 – Annex A: 2008: | Electrostatic discharge to the PT4 may cause it to spontaneously turn on. If this occurs, the PT4 will turn off. |
| WARNING! These products can expose you to chemicals including Di(2-ethylhexyl)phthalate (DEHP), which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. |
