Nem Ölçer Anhidrit Alçı Kağıt GHM3831 GEF38

Resistive material moisture and temperature measuring device

Conform to EN 14080 : 2013 EN 16351 : 2015 Suitable e.g. for glued timber construction and laminated timber (MPA certified and listed)

HIGHLIGHTS:

• serial interface or analog output 0 ... 1 V, freely scalable
• incl. calibration protocol

GENERAL:

The GMH 3831 offers decisive advantages in handling, user-friendliness, functional range and accuracy. The absolute moisture of 494 material types is displayed directly and can be automatically converted to water content. The cumbersome usage of calculation tables becomes a thing of the past. Additionally you get a moisture rating (wet ... dry) of the measured material.

APPLICATION:

Precision measurements in cut-wood, chip board, veneer, sawdust, wood chips, wood wool, flax, straw, hay, concrete, bricks, wash floor, plaster, limestone mortar, cement mortar, paper, carton, textiles, wood chips, professional firewood humidity measurement, etc.
For architect, expert, inspector, building contractor, painter, carpenter, parquet joiner, floor tiler, wood works, timber desiccation plant, building repair company, textile industry etc.

SPECIFICATIONS:

Measuring principle
Moisture:
Resistive material moisture measurement acc. to DIN EN 13183-2:2002
Temperature
external:
thermocouple, NiCr-Ni (type K)
internal:
NTC
Characteristic curves:
494 material characteristics
Measuring range:
Moisture:
0.0 ... 100 % u (material moisture)
0.0 ... 50 % w (water content, wet basis)
(depends on selected characteristic)
Temperature:
-40.0 ... +200.0 °C (-40.0 ... +392.0 °F)
Moisture rating:
9 steps (dry ... wet)
Resolution:
0.1 % or 0.1 °C (0.1 °F)
Device accuracy: (at nominal temperature)
Wood:
±0.2 % material moisture (deviation from corresponding characteristic curve in range 6 ... 30 %)
Building material:
±0.2 % material moisture (deviation from corresponding characteristic curve)
Temperature:
(external) ± 0.2 % of m.v. ± 0.3 °C
Scope of supply:
Device, battery, calibration protocol, manual
